📌 Lovable Forms Series · Part 6 of 6
The closing chapter: when your form needs to receive applications, contracts, screenshots or PDFs, you need more than <input type="file">. Here's how to do it right.

File Uploads in Lovable Forms: Drag & Drop, Supabase Storage, RLS and Signed URLs

File uploads are the classic feature MVPs fail on: either the UX is ugly (browser default), validation is missing (50 MB application PDF crashes the server), or security is wide open (public bucket with every applicant's CV).

In this part we build the full stack: a slick drag-and-drop UI, client and server validation, secure Supabase Storage buckets with RLS, and time-limited access via signed URLs.

---

Architecture

[react-dropzone UI]
        ↓ (client validation)
[Supabase Storage upload]
        ↓ (RLS policies)
[Bucket: form-uploads (private)]
        ↓ (Edge Function)
[signed URL for sales/HR team]

Golden rule: uploads ALWAYS land in private buckets. Never public, not even "just briefly".

---

Step 1: Bucket + RLS in Lovable Cloud

In the Supabase console, create a bucket form-uploads. Public off. Then this migration:

-- Bucket setup (if not via UI)
insert into storage.buckets (id, name, public)
values ('form-uploads', 'form-uploads', false)
on conflict (id) do nothing;

-- RLS: anon users may ONLY upload to their own submission folder
-- Folder structure: form-uploads/{submission_id}/{filename}
create policy "anon can upload to own submission folder"
on storage.objects
for insert
to anon
with check (
  bucket_id = 'form-uploads'
  and (storage.foldername(name))[1] = current_setting('request.jwt.claims', true)::json->>'submission_id'
);

-- Nobody except service_role may read (downloads via signed URL)
create policy "no public read"
on storage.objects
for select
to anon, authenticated
using (false);

⚠️ Important: the submission_id comes from a short-lived JWT issued by an Edge Function – not from the frontend. Otherwise anyone could guess IDs.

---

Step 2: Upload-token Edge Function

Before uploading, the frontend grabs an upload token (valid ~10 min) and a fresh submission_id.

// supabase/functions/issue-upload-token/index.ts
import { serve } from "https://deno.land/std@0.168.0/http/server.ts";
import { create } from "https://deno.land/x/djwt@v3.0.1/mod.ts";

const corsHeaders = {
  "Access-Control-Allow-Origin": "*",
  "Access-Control-Allow-Headers": "authorization, x-client-info, apikey, content-type",
};

serve(async (req) => {
  if (req.method === "OPTIONS") return new Response(null, { headers: corsHeaders });

  const submissionId = crypto.randomUUID();
  const secret = Deno.env.get("SUPABASE_JWT_SECRET")!;

  const key = await crypto.subtle.importKey(
    "raw", new TextEncoder().encode(secret),
    { name: "HMAC", hash: "SHA-256" }, false, ["sign"]
  );

  const jwt = await create(
    { alg: "HS256", typ: "JWT" },
    {
      role: "anon",
      submission_id: submissionId,
      exp: Math.floor(Date.now() / 1000) + 600, // 10 min
    },
    key
  );

  return new Response(JSON.stringify({ submissionId, uploadToken: jwt }), {
    headers: { ...corsHeaders, "Content-Type": "application/json" },
  });
});

---

Step 3: Drag & Drop UI with react-dropzone

import { useDropzone } from "react-dropzone";
import { Upload, X, FileText } from "lucide-react";

const MAX_SIZE = 10 * 1024 * 1024; // 10 MB
const ACCEPTED = {
  "application/pdf": [".pdf"],
  "image/jpeg": [".jpg", ".jpeg"],
  "image/png": [".png"],
};

export function FileUploadField({ onChange }: { onChange: (files: UploadedFile[]) => void }) {
  const [files, setFiles] = useState<UploadedFile[]>([]);

  const onDrop = useCallback(async (accepted: File[]) => {
    // 1. Get token
    const { data: tokenData } = await supabase.functions.invoke("issue-upload-token");
    const { submissionId, uploadToken } = tokenData;

    // 2. Upload
    const uploaded: UploadedFile[] = [];
    for (const file of accepted) {
      const path = `${submissionId}/${crypto.randomUUID()}-${file.name}`;
      const { error } = await supabase.storage
        .from("form-uploads")
        .upload(path, file, {
          headers: { Authorization: `Bearer ${uploadToken}` },
          cacheControl: "3600",
          upsert: false,
        });
      if (error) {
        toast.error(`Upload failed: ${file.name}`);
        continue;
      }
      uploaded.push({ name: file.name, path, size: file.size });
    }
    const next = [...files, ...uploaded];
    setFiles(next);
    onChange(next);
  }, [files, onChange]);

  const { getRootProps, getInputProps, isDragActive } = useDropzone({
    onDrop,
    accept: ACCEPTED,
    maxSize: MAX_SIZE,
    multiple: true,
  });

  return (
    <div className="space-y-2">
      <div
        {...getRootProps()}
        className={`border-2 border-dashed rounded-lg p-8 text-center cursor-pointer transition
          ${isDragActive ? "border-primary bg-primary/5" : "border-muted-foreground/30"}`}
      >
        <input {...getInputProps()} />
        <Upload className="mx-auto h-8 w-8 text-muted-foreground" />
        <p className="mt-2 text-sm">
          {isDragActive ? "Drop to upload" : "Drop PDF, JPG or PNG here, or click"}
        </p>
        <p className="text-xs text-muted-foreground">Max. 10 MB per file</p>
      </div>

      {files.map((f, i) => (
        <div key={i} className="flex items-center justify-between rounded border p-2">
          <span className="flex items-center gap-2 text-sm"><FileText className="h-4 w-4" />{f.name}</span>
          <button onClick={() => removeFile(i)}><X className="h-4 w-4" /></button>
        </div>
      ))}
    </div>
  );
}

---

Step 4: Server-side validation (mandatory)

Client validation is UX only. Real validation happens in the submit Edge Function:

// supabase/functions/submit-application/index.ts
const ALLOWED_TYPES = ["application/pdf", "image/jpeg", "image/png"];
const MAX_BYTES = 10 * 1024 * 1024;

// For every uploaded file:
const { data: head } = await supabaseAdmin.storage
  .from("form-uploads")
  .info(file.path); // metadata

if (!ALLOWED_TYPES.includes(head.contentType)) {
  await supabaseAdmin.storage.from("form-uploads").remove([file.path]);
  throw new Error("Invalid file type");
}
if (head.size > MAX_BYTES) {
  await supabaseAdmin.storage.from("form-uploads").remove([file.path]);
  throw new Error("File too large");
}

💡 Bonus for regulated industries: chain a virus scan via ClamAV as a second Edge Function. On infected → delete file + reject submission.

---

Step 5: Signed URLs for read access

When the HR team opens an application from your internal dashboard, never make the bucket public. Instead:

const { data, error } = await supabaseAdmin.storage
  .from("form-uploads")
  .createSignedUrl(file.path, 60 * 5); // 5 minutes

return data.signedUrl;

The URL has a one-time token, expires, can't be shared. Perfect for "Click to open the CV".

---

Pitfalls

Problem	Cause	Fix
50 MB limit (Supabase Free)	Bucket default	Upgrade plan or use multi-part upload
CORS error on direct upload	Bucket CORS config missing	In Supabase dashboard: Storage → Configuration → Allowed Origins
User sees bucket listing	Wrong RLS policy	Explicit for select using (false)
File lingers after form abort	No cleanup	Cron Edge Function: delete form-uploads/* older than 24h without DB row
Mimetype spoof (.jpg = .exe)	Only extension checked	Server-side: check head.contentType + magic-number check

---

Conclusion

File uploads in Lovable aren't complicated – they just have many layers that all need to be right: UI, token, bucket, RLS, server validation, signed URLs. Skip one and you either have no upload (UI/token) or a data leak (RLS).

With the stack shown here you get both: nice drag & drop UX and HR-/GDPR-grade security.

---

That wraps up the series

You now have the full spectrum:

Part	Focus
1	SaaS tools (Tally, Typeform, WorkForms)
2	Custom build (RHF + zod + Lovable Cloud)
3	Production-ready best practices
4	monday.com integration via GraphQL
5	Smart forms with AI
6	File uploads & storage (you are here)

Want the whole series as a consulting workshop? Talk to us – we build form stacks from the first line of code all the way to the CRM entry.
